Suntek is a professional PCBA solution provider,specilizes in PCB
production,components procurement,PCB assembly and a series service
of wire harness and Box building.
We have high-qualified management team, experienced
engineering,quality control&production team and skilled
employees and possess advantaged supply chain,commitment to good
quality,competitive price and on-time on delivery.
Capabilities overview:
Layers: | Rigid PCB 2 - 40 + Layers, Rigid-flex PCB 1 - 10Layers |
Panel Size(max): | 21" x 24" |
PCB Thickness: | 0.016" to 0.120" |
Line & Spaces: | 0.003" / 0.003" Inner Layers; 0.004" Outer Layers |
Hole Size: | 0.006" Thru Hole (Finished Size) and 0.004" Buried Via |
Materials: | FR4, High Tg, Rogers, Halogen-free material, Teflon, Polyimide |
Surface Finishes: | ENi/IAu, OSP, Lead-free HASL,Immersion Gold/Silver, Immersion Tin |
Special Products: | Blind/ Buried Via(HDI 2+N+2), Rigid Flex |
A Flex Circuit or Flex PCB is a patterned arrangement of printed
circuitry and components that utilizes flexible based material with
or without flexible coverlay.
A Flex Circuit or Flex PCB is a patterned arrangement of printed
circuitry and components that utilizes flexible based material with
or without flexible coverlay. These flexible electronic assemblies
may be fabricated using the same components used for rigid printed
circuit boards, but allowing the board to conform to a desired
shape (flex) during its application.
How many layer can a flexible PCB be ?
Maximum 10 layers for flexible PCB.
How copper thichness can a flexible PCB be ?
2oz,only some flexible led PCBs like heavy copper,the best
advantage of flexible PCB is flex,if too much copper,willnot be
easy to bent for your device.
How big size can a flexible PCB be ?
Flexible PCB material:maximum width is 250mm,because flexible PCB
material is a roll,each roll width is 250mm,the length is no
limit,so when you design flexible PCB,one side should be less than
250mm,the other side no care .
How thickness can a flexible PCB be ?
0.1mm - 0.2mm,some flexible PCB can be 0.3mm .
Applications:
LED and Lighting equipments
Smart mobile phone
Medical equipments
Aerospace product
Instrumentation
Service Offerings:
- Innovative Rigid-Flex Processes
- Premium Material Sets
- Rigid-Flex with HDI
- Loose Leaf Construction
- Oversized Panels
- Layer counts to 40+
- Heat Sink Application
Applications:
The flexible circuit boards are a right match for applications that
require better performance, high accuracy, precision, and regular
flexing. Applications of flexible circuit boards include:
- Cameras
- Antilock brakes
- Fuel pumps
- Ultrasound probes
- Semiconductor test
- Medical devices
- Motion systems
- Satellites
- Avionics
- Battery packs
- Manufacturing devices
- Airbag systems
